Names of Machine Parts
GETTING READY
7
1
Included accessories
Included accessories may differ from the table below depending on the machine model you purchased. For more details on
included accessories and their part codes of your machine, refer to the additional sheet “Included Accessories”.
Pull the top of the flat bed attachment to open the accessory compartment.
1. 2. 3. 4. 5. 6.
Zigzag foot “J” (on machine) Monogramming foot “N” Overcasting foot “G” Zipper foot “I” Blind stitch foot “R” Button fitting foot “M”
7. 8. 9. 10. 11. 12.
Buttonhole foot “A” Embroidery foot “Q”
Needle set
*1
Twin needle
*2
Bobbin
(on machine)
Pre-wound bobbin (60 weight
white embroidery bobbin
thread)
13. 14. 15. 16. 17. 18.
Bobbin clip Seam ripper Scissors Cleaning brush Eyelet punch Screwdriver
19. 20. 21. 22. 23. 24.
Disc-shaped screwdriver Extra spool pin Spool cap (large) Spool cap (medium)
(on machine)
Spool cap (small) Thread spool insert
(mini king thread spool)
25. 26. 27. 28. 29.
Bobbin case
(on machine)
Spool net Foot controller Embroidery frame set (medium)
10 cm (H) × 10 cm (W) (4 inches (H) × 4 inches (W))
Accessory bag
30. 31. 32.
Operation Manual Quick Reference Guide Embroidery Design Guide
*1
75/11 2 needles,
90/14 2 needles,
90/14 2 needles: Ball point needle (gold colored)
*2
2/11 needle
Note
• (For U.S.A. only) Foot controller: Model T
This foot controller can be used on the machine with product code 888-M20. The product code is mentioned on the
machine rating plate.
J
N
G
I
R
M
M
A
Q
