Brother MFC-7220 User Manual

8-8 Confidential
8.4.3 ADF Performance Test (Function code 08)


 Function
The machine counts the documents fed by the automatic document feeder (ADF) and
displays the count on the LCD for checking the ADF performance.


 Operating Procedure
(1) Set documents. (Allowable up to the ADF capacity.)
The "DOC. READY" will appear on the LCD.
(2) Press the 0 and 8 keys in this order.
While counting the documents, the machine feeds them in and out, displaying the
current count on the LCD as shown below.
Current count (1st page in this example)
(3) To return the machine to the initial stage of the maintenance mode, press the Stop/Exit
key.

Brother MFC-7220 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	20 ppm
PC free copying	Yes
Copy speed (black, normal quality, A4)	20 cpm
Faxing	Mono faxing
Modem speed	14.4 Kbit/s
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Market positioning	Home & office
Internal memory	16 MB
Dimensions (WxDxH)	452.12 x 492.76 x 429.26 mm
Power requirements	AC 120V 50/60Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Print
Compatible operating systems	Windows & Mac OS
Bundled software	Scansoft PaperPort SE with OCR for Windows and Presto PageManager for Mac
Sustainability certificates	ENERGY STAR
Power consumption (off)	10 W
Power consumption (standby)	75 W
Power consumption (average operating)	1032 W
Operating temperature (T-T)	50 - 91 °C
Non-operating relative humidity (non-condensing)	20 - 80 %
Digital sender	No
Maximum duty cycle	10000 pages per month

Weight and Dimensions

Weight	10795 g
