Brother MFC-7220 User Manual

Confidential
5-2
 Tightening Torque
Location of screw Screw type Q'ty Tightening torque
N•m (kgf•cm)
Document base ASSY
Side cover L
Speaker hold spring
Taptite, cup B M4x12
Taptite, bind B M4x12
Taptite, cup B M3x8
2
2
1
0.79 ±0.1 (8 ±1)
0.79 ±0.1 (8 ±1)
0.49 ±0.1 (5 ±1)
Side cover R Taptite, bind B M4x12 2 0.79 ±0.1 (8 ±1)
ADF plate spring Taptite, cup B M3x6 1 0.49 ±0.1 (5 ±1)
Panel rear cover Taptite, cup B M3x8 3 0.46 ±0.05 (4.5 ±0.5)
Rear cover stopper Taptite, bind B M4x12 1 0.79 ±0.1 (8 ±1)
Inner chute Taptite, bind B M4x12 2 0.79 ±0.1 (8 ±1)
LV shield plate cover Screw, pan (s/p washer) M3.5x6 1 0.49 ±0.1 (5 ±1)
Top cover ASSY Taptite, bind B M4x12 2 0.79 ±0.1 (8 ±1)
LF ground plate Taptite, cup S M3x6 1 0.69 ±0.1 (7 ±1)
LF FG harness ASSY Taptite, cup B M3x4 1 0.39 ±0.1 (4 ±1)
Inner chute cover ASSY Taptite, bind B M4x12 4 0.79 ±0.1 (8 ±1)
Scanning driver ASSY Taptite, cup B M3x8 2 0.49 ±0.1 (5 ±1)
Scanning motor F sub ASSY Screw, pan (s/p washer) M3x6 1 0.69 ±0.1 (7 ±1)
NCU FG harness Screw, pan (s/p washer) M3.5x6 1 0.49 ±0.1 (5 ±1)
NCU unit Taptite, bind B M4x12 2 0.78 ±0.1 (8 ±1)
NCU PCB ASSY Taptite, cup S M3x6 2 0.49 ±0.1 (5 ±1)
Chute base Taptite, bind B M4x12 6 0.8 ±0.1 (8 ±1)
Fixing unit Taptite, cup B M4x12 2 0.78 ±0.1 (8 ±1)
Halogen heater Screw, pan (s/p washer) M3x8 2 0.59 ±0.05 (6 ±0.5)
Thermistor ASSY Taptite, cup B M3x12 1 0.59 ±0.1 (6 ±1)
Taptite, bind B M4x12 2 0.78 ±0.1 (8 ±1)
High voltage PS PCB
Taptite, cup S M3x6 2 0.69 ±0.1 (7 ±1)
CDCC PCB Screw, Pan M3x6 2 0.49 ±0.1 (5 ±1)
Main PCB Taptite, cup S M3x6 5 0.69 ±0.1 (7 ±1)
FG harness ASSY 1 Screw, pan (S/P washer) M3.5x6 1 0.59 ±0.1 (6 ±1)
LV shield plate cover Taptite, cup S M3x6 2 0.69 ±0.1 (7 ±1)
Taptite, bind B M4x12 2 0.78 ±0.1 (8 ±1) LV shield plate
Screw, pan (s/p washer) M3.5x6 1 0.59 ±0.1 (6 ±1)
AC holder Taptite, bind B M4x12 1 0.59 ±0.1 (6 ±1)
PS PCB unit Taptite, cup S M3x6 2 0.69 ±0.1 (7 ±1)
Laser unit Taptite, cup S M3x6 4 0.69 ±0.1 (7 ±1)
FG harness ASSY 6 Taptite, cup S M3x6 1 0.69 ±0.1 (7 ±1)
Air duct Taptite, cup S M3x6 2 0.69 ±0.1 (7 ±1)
Sub chute ASSY Taptite, bind B M4x12 2 0.78 ±0.1 (8 ±1)
Regist sensor PCB ASSY Taptite, bind B M3x6 1 0.39 ±0.1 (4 ±1)
Base plate Taptite, bind B M4x12 3 0.78 ±0.1 (8 ±1)
Toner sensor PCB ASSY Taptite, cup B M3x6 1 0.25 ±0.05 (2.5 ±0.5)
Main shield plate Taptite, bind B M4x12 4 0.78 ±0.1 (8 ±1)
Gear plate calking ASSY Taptite, bind B M4x12 3 0.78 ±0.1 (8 ±1)
Main motor ASSY Taptite, cup S M3x6 3 0.69 ±0.1 (7 ±1)
P/R solenoid ASSY Taptite, bind B M3x10 1 0.49 ±0.1 (5 ±1)
F/R solenoid ASSY Taptite, bind B M3x10 1 0.49 ±0.1 (5 ±1)
Main frame L Taptite, bind B M4x12 2 0.78 ±0.1 (8 ±1)
Main frame R Taptite, bind B M4x12 3 0.78 ±0.1 (8 ±1)

Brother MFC-7220 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	20 ppm
PC free copying	Yes
Copy speed (black, normal quality, A4)	20 cpm
Faxing	Mono faxing
Modem speed	14.4 Kbit/s
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Market positioning	Home & office
Internal memory	16 MB
Dimensions (WxDxH)	452.12 x 492.76 x 429.26 mm
Power requirements	AC 120V 50/60Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Print
Compatible operating systems	Windows & Mac OS
Bundled software	Scansoft PaperPort SE with OCR for Windows and Presto PageManager for Mac
Sustainability certificates	ENERGY STAR
Power consumption (off)	10 W
Power consumption (standby)	75 W
Power consumption (average operating)	1032 W
Operating temperature (T-T)	50 - 91 °C
Non-operating relative humidity (non-condensing)	20 - 80 %
Digital sender	No
Maximum duty cycle	10000 pages per month

Weight and Dimensions

Weight	10795 g
