Brother MFC-7220 - Top Cover

Confidential
5-21
5.1.13 Top Cover
(1) Remove the bind B M4x12 taptite screw, and then remove the rear cover stopper.
(2) Remove the two bind B M4x12 taptite screws, and the rear chute cover spring.
(3) Remove the inner chute.
Hoo
k
s
Tap
t
ite,
b
ind B M4x12
Rear cover stoppe
r
Top cove
r
Inner chute
Rear chute cover spring
Taptite,
b
ind B M4x12
Taptite,
b
ind B M4x12
Hoo
k
