Scanning
65
Pre-Scanning to crop a portion you want to scan using the scanner glass 3
The Preview button is used to preview an image for cropping any unwanted portions from the image. When
you are satisfied with the preview, click the Scan button in the Scan dialog box to scan the image.
a Follow the steps from a to e of Scanning a document into the PC uu page 63.
b Put the document face down on the scanner glass.
c Choose Flatbed in the Source drop-down list. Adjust the additional settings, if needed, in the Scan
dialog box.
d Click Preview.
The whole image is scanned into the PC and appears in the scanning area.
e Press and hold down the left mouse button and drag it over the portion you want to scan.
f Click Scan in the Scan dialog box.
The machine starts scanning the document.
This time only the chosen area of the document appears in your application window.
