Carton components may differ from one country to another.
Save all packing materials and the carton.
Warning
■ When you move the MFC, gra sp th e side ha nd ho lds th at a re unde r t he sca nn er. Do NO T carry th e MFC by h oldin g
it at the b ot tom.
Carton Components
Quick Setup Guide
CD-ROMs
For Wi ndows
®
For Macin tosh
®
User’s Guide
ADF Support Drum Unit Assemb ly
(including Toner Cartridge)
AC Power Cord
Telephone
Line Cord
Te st S hee t
(USA only)
Accessory Order Form
(USA/Canada only)
■ The interface cable is not a standard accessory. Please purchase the appropriate interface cable for the interface
you intend to use (Parallel or USB).
■ For Pa rallel u se a b i-direction al sh ield inte rf ace ca ble tha t is I EEE 1 28 4-comp lia nt, an d no t lon ge r than 6 fee t
(2 meters).
■ For USB: use a Hi-Speed USB 2.0 interface cable that is not longer than 6 feet (2 meters).
■ Please make sure that you use a Hi-Speed USB 2.0 certified cable if your computer uses a Hi-Speed USB 2.0
in te rf ace .
■ Even if your computer has a USB 1.1 interface, you can connect the MFC.
4
3
1
1
. Control Panel
2. Face-down Output Tray
Support Flap with Extension
(Support Flap)
3. (For MFC-8420) Manual Feed Tray
(For MFC-8820D and MFC-8820DN)
Multi-purpose Tray (MP Tray)
2
MFC
5
6
4
. Paper Tray
5. Front Cover
6. Power Switch
7. Document Cover
8.
Automatic Document Feeder (ADF)
7
8
