Brother MFC-8860DN Service Manual

Confidential
9-7
Error Code
(Hex)
Symptom Probable Cause
Solution
Separation pad damaged Replace the separation
pad ASSY.
83
Recording paper jam. (The
registration sensor comes ON
too early in the paper feeding
operation.)
Registration sensor
actuator does not move
smoothly.
Set the registration sensor
actuator into place.
Foreign materials in the
paper path
Remove foreign materials.
The paper ejection roller
does not rotate correctly.
Replace the paper ejection
roller.
Ejection sensor actuator
does not move smoothly.
Set the ejection sensor
actuator into place.
Ejection sensor defective Replace the relay rear
PCB ASSY.
84
Recording paper jam. (The
ejection sensor stays ON
after completion of paper
ejection operation.)
Main PCB defective Replace the main PCB.
PE PG sensor defective Replace the PE PG sensor.85 No paper tray1 loaded.
Main PCB defective Replace the main PCB.
PE PG sensor of LT
defective
Replace the PE PG sensor
of LT.
86 No paper tray2 loaded.
Main PCB defective Replace the main PCB.
87 Not used.
Foreign materials in the
machine
Remove foreign materials
in the machine.
Regist actuator rear does
not move smoothly.
Set the regist actuator rear
into place.
Fuser unit defective Replace the fuser unit.
Breakage of the gear in
the frame L ASSY
Replace the frame L
ASSY.
Regist rear sensor
defective
Replace the high-voltage
PS PCB.
PE PG sensor defective Replace the PE PG sensor.
88
Recording paper jam. (Even
after paper pulling-in
operation, the regist rear
sensor is still OFF.)
Main PCB defective Replace the main PCB.
89 Not used.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
