Brother MFC-8860DN Service Manual

Confidential
9-8
Error Code
(Hex)
Symptom Probable Cause
Solution
The paper trays T1 and T2
are mounted oppositely.
Switch the paper trays T1
and T2.
Foreign materials between
the tray and front
registration sensor
Remove foreign materials.
PF roller defective Replace the PF roller.
Separation pad ASSY
defective
Replace the separation
pad ASSY.
T2 solenoid defective Replace the T2 solenoid
Regist actuator front does
not move smoothly.
Set the regist actuator
front into place.
Regist actuator front
defective
Replace the regist actuator
front.
Regist front sensor
defective
Replace the high-voltage
PS PCB.
8A Jam tray2
Main PCB defective Replace the main PCB.
Foreign materials between
the tray and front
registration sensor
Remove foreign materials.
PF roller defective Replace the PF roller.
Separation pad ASSY
defective
Replace the separation
pad ASSY.
T1 solenoid defective Replace the T1 solenoid.
Regist actuator front does
not move smoothly.
Set the regist actuator
front into place.
Regist actuator front
defective
Replace the regist actuator
front.
Regist front sensor
defective
Replace the high-voltage
PS PCB.
8B Jam tray1
Main PCB defective Replace the main PCB.
MP tray defective Replace the MP tray.
PF roller defective Replace the PF roller.
Separation pad ASSY
defective
Replace the separation
pad ASSY.
MP solenoid defective Replace the MP solenoid.
Regist actuator front does
not move smoothly.
Set the regist actuator
front into place.
Regist actuator front
defective
Replace the regist actuator
front.
Regist front sensor
defective
Replace the high-voltage
PS PCB.
8C Jam MP tray
Main PCB defective
Replace the main PCB.
8D-A0 Not used.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
