Brother MFC-8860DN Service Manual

Confidential
9-9
Error Code
(Hex)
Symptom Probable Cause
Solution
Hook of the front cover
sensor on the front cover
b
roken.
Replace the front cover.
A1 Front cover opened.
Front cover sensor
defective
Replace the front cover
sensor.
Document jam Remove the jammed
document.
A2
Document length exceeding
the scan limitation.
During scanning, 90 cm or
longer of a document is
detected.
During document feeding or
ejecting, 400 cm or longer of
a document is detected.
Document rear sensor
actuator does not move
smoothly.
Set the document rear
sensor actuator into place.
Document jam Remove the jammed
document.
Document rear sensor
actuator does not move
smoothly.
Set the document rear
sensor actuator into place.
A3 The document rear sensor
does not come ON during
document pull-in operation.
Document rear sensor
broken
Replace the document rear
sensor.
A4 Not used.
A5 FAX scanning failure.
(1st time)
White-level reference film
stained in the scanner
cover
Replace the scanner cover
(scanner unit).
CCD unit defective Replace the CCD unit.
A6 FAX scanning failure. (retry)
Main PCB defective Replace the main PCB.
A7-A9 Not used.
AA The document cover is
opened when the ADF is
used.
Document cover sensor
defective
Replace the document
cover sensor.
AB Not used.
AC-AE Not used.
Scanner lock lever
defective
Replace the scanner lock
lever.
AF The scanner is locked.
Driver PCB defective Replace the driver PCB.
B0 Not used.
Scan level error Execute the maintenance
mode 55.
CCD unit defective Replace the CCD unit.
B1 Dark level offset data level
error for scanning.
Main PCB defective Replace the main PCB.
Scan level error Execute the maintenance
mode 55.
CCD unit defective Replace the CCD unit.
B2 Gain control data level error
for scanning.
Main PCB defective Replace the main PCB.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
