Brother MFC-8860DN Service Manual

Confidential
9-10
Error Code
(Hex)
Symptom Probable Cause
Solution
Black markings on the
white-level reference film
inside the scanner top
cover.
Clean the white-level
reference film.
CCD unit defective Replace the CCD unit.
B3 Scan area left edge detection
error.
Main PCB defective Replace the main PCB.
Black markings on the
white-level reference film
inside the scanner top
cover.
Clean the white-level
reference film.
CCD unit defective Replace the CCD unit.
B4 Scan area right edge
detection error.
Main PCB defective Replace the main PCB.
Black markings on the
white-level reference film
inside the scanner top
cover.
Clean the white-level
reference film.
CCD unit defective
Replace the CCD unit.
B5
Horizontal scanning edge
reduction detection error in
scanning area setting
Main PCB defective Replace the main PCB.
Black markings on the
white-level reference film
inside the scanner top
cover.
Clean the white-level
reference film.
CCD unit defective Replace the CCD unit.
B6
Horizontal scanning edge
enlargement detection error
in scanning area setting
Main PCB defective Replace the main PCB.
B7-BA Not used.
Scan level error Execute the maintenance
mode 55.
CCD unit defective Replace the CCD unit.
BB White level data error
Main PCB defective Replace the main PCB.
BC Not used.
Scan level error Execute the maintenance
mode 55.
CCD unit defective Replace the CCD unit.
BD Black level data error
Main PCB defective Replace the main PCB.
Black markings on the
white-level reference film
inside the scanner top
cover.
Clean the white-level
reference film.
CCD unit defective Replace the CCD unit.
BE Scan starting edge detection
error
Main PCB defective Replace the main PCB.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
