Brother MFC-L2700DN Service Manual

5-49
Confidential
ENVLOP:00000000 Paper input for Envelope
A5 :00000000 Paper input for A5 (including A5 Landscape)
OTHER :00000000 Paper input for other sizes
PLTNRE:00000000 Printed pages of plain, thin, and recycled paper
TKTRBD:00000000 Printed pages of thick, thicker, and bond paper
ENVTYP:00000000 Printed pages of envelope, thick envelope, and thin envelope
LABEL:00000000 Printed labels
HAGAKI:00000000 Printed postcards
TTL_JAM:00000000 Total paper jams
TR1_JAM:00000000 Paper jams that have occurred in paper tray
IN_JAM:00000000 Paper jams that have occurred in the center of the machine
RE_JAM:00000000 Paper jams that have occurred around the back cover
DX_JAM:00000000 Paper jams that have occurred in the duplex tray
POWER:00000375 Total power distribution time (hour)
PWRCNT:00000001 The number of times that the power is turned ON
KTN_CH:0000 The number of times that the toner cartridge has been replaced
*4
DRUM_CH:0000 The number of times that the drum unit has been replaced
*4
KTN_PG1:00000000 Pages printed with the current toner cartridge
KTN_PG2:00000000 Pages printed with the previous toner cartridge
ADF_PG:000000000 ADF scanned pages (single-side scanning models only)
ADSX_PG:00000000 ADF single-side scanned pages (duplex scanning models only)
ADDX_PG:00000000 ADF duplex scanned pages (duplex scanning models only)
FB_PG:000000 FB scanned pages
ADF_JAM:0000000 Document jams that have occurred on ADF scanning
(single-side scanning models only)
ADSX_JAM:000000 Document jams that have occurred on ADF single-side scanning
(duplex scanning models only)
ADDX_JAM:000000 Document jams that have occurred on ADF duplex scanning
(duplex scanning models only)
COMERR#:00000000 Communication error log (past three errors)
*5
(models with fax only)
KDEV_BIAS:400V Developing bias voltage value
ENGERR##:000000 Engine error log (past ten errors)
*6
HODN_ER:0000 The number of discharge errors occurred
FUSR_ER:0000 The number of fuser unit errors occurred
MTLK_ER:0000 The number of polygon motor lock errors occurred in the laser
scanner
DEVSTATUS__##:00 Log for design analysis
*7
LCD Description

Brother MFC-L2700DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	24 ppm
Product color	Gray
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	45 dB
Maximum copy resolution	600 x 600 DPI
Scanner type	Flatbed & ADF scanner
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	SMTP-AUTH, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Package depth	517 mm
Package width	567 mm
Package height	435 mm
Package weight	14400 g
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11, SuSE Linux 11.1, SuSE Linux 11.2, SuSE Linux 12.0
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 2000 pages per month

Weight and Dimensions

Depth	398.5 mm
Width	409 mm
Height	316.5 mm
