Brother P-Touch PT-2730 Service Manual

I - 7
1.2 Electronics Specifications
1.2.1 Character Generator
(1) Internal font HELSINKI, BRUSSELS, US, FLORIDA,
BELGIUM, SAN DIEGO, LOS ANGELS,
CALGARY
(2) Text buffer 280 characters
(3) File memory 2800 characters
1.2.2 Power Supply
(1) Power supply Two types (dry cells, AC adapter)
(2) Battery type 8 alkaline dry cells (AA)
(3) Service life of batteries Will last through one 24-mm wide tape cassette
and then some.
(4) Automatic powering-off Yes
(5) AC adapter AD-24ES US
AD-24ES EU
AD-24ES UK
AD-5000ES AUS
1.3 Key Commands for Special Functions
1.3.1 Initializing
When the machine is turned off, press the [ON/OFF] key while pressing both the
[Space] and [BS] keys so that the machine initializes the internal memory.
Dry cells AC adapter
P-touch labeler only 5 min 480 min
Connected to PC 60 min 480 min

Brother P-Touch PT-2730 Specifications

General

Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	180 x 180 DPI
Maximum print height	18 mm
Display	LCD
Product color	Black, White
Keyboard layout	QWERTY
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Tape size	24 mm
Dimensions (WxDxH)	177.8 x 238.7 x 71.1 mm
Battery type	AA
Battery technology	Alkaline
Number of batteries supported	8
Minimum RAM	128 MB
Minimum storage drive space	70 MB
Compatible operating systems	Windows XP, Windows Vista, Windows 7; Mac OS X 10.4.11 - 10.6.x
Tape type	TZ
Tape cutting	Automatic
Number of styles	11
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, Industrial 2/5, UPC-A, UPC-E
Ribbon length	8 m
Maximum label length	300 m

Weight and Dimensions

Depth	238.7 mm
Width	177.8 mm
Height	71.1 mm
Weight	861 g
