General Description
1. Cover latch
2. Tape exit slot
3. LCD display
4. Mini-USB port
5. Keyboard
6. Tape cutter
7. Tape cassette compartment
8. Release lever
9. Print head
1. Tape viewer
2. Rear cover
3. AC adapter connector
4. LED lamp
5. Battery compartment
General Description
1
2
3
5
4
6
7
8
9
When shipped from the factory, the LCD display is covered with a protective sheet to prevent
damage. Remove this sheet before using the P-touch labeling system.
