Brother P-Touch PT-E500 Quick Setup Guide

 GETTING STARTED
31
Setting Language and Unit
Language
Press the Menu key, select " Language" using the or key, and then press the
OK or Enter key.
Select a language for menu commands and messages shown on the LCD display by
using the or key.
The language can be selected from "Čeština", "Dansk", "Deutsch", "English", "Español",
"Français", "Hrvatski", "Italiano", "Magyar", "Nederlands", "Norsk", "Polski",
"Português", "Português (Brasil)", "Română", "Slovenski", "Slovenský", "Suomi",
"Svenska" or "Türkçe".
Press the OK or Enter key.
Unit
Press the Menu key, select "Unit" using the or key, and then press the OK or Enter
key.
Select a unit for dimensions shown on the LCD display by using the or key.
Either "inch" or "mm" can be selected.
Press the OK or Enter key.
Setting Language and Unit
1
2
3
Press the Esc key to return to the previous step.
1
2
3
The default setting is "mm".
Press the Esc key to return to the previous step.

Brother P-Touch PT-E500 Specifications

General

Color	-
Print technology	Thermal transfer
Maximum resolution	180 x 180 DPI
Maximum print height	18 mm
Maximum printing width	24 mm
Display	LCD
Product color	Black, Orange
Backlight display	Yes
Display number of lines	3 lines
Display number of characters	16
Label type	3.5 / 6/9/12/18/24 mm (Tz), 5.8 / 8.8 / 11.7 / 17.7 / 23.6 mm (HSe)
Number of frames	7
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
Maximum label length	8 m
Tape type	TZe
Tape cutting	Automatic
Number of fonts	14
Number of styles	10
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, GS1-128, ITF-25, UPC-A, UPC-E
Battery type	Built-in battery
Mac operating systems supported	Mac OS X 10.5 Leopard
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	250 mm
Width	126 mm
Height	94 mm
Weight	920 g
