Brother PE-DESIGN LITE User Manual

50
Arranging Embroidery Designs
2. Click or File, then Write to Card, then
Current Design.
→ The following message appears.
3. Click OK.
→ The message “Now transmitting” appears
while the current embroidery design is
transferred to the original card, and then
the following message appears.
4. Click OK to close the message.
■ Writing multiple embroidery files
to an original card
You can save multiple .pes files to an original card
at the same time.
1. Insert an original card into the USB card writer
module.
2. Click File, then Write to Card, then Other
PES files.
→ The following dialog box appears with the
contents of the last folder accessed
displayed in the available patterns list.
a Note:
• If the original card is not brand new,
make sure that the designs already
stored on the card are no longer
needed.
• If no original card is inserted, the
following message appears
• Insert an original card, and then click
Retry .
• To quit the operation, click
Cancel .
• If a .pes file is saved with objects
extending off the Design Page or with
the number of stitches or number of
colors for the objects exceeding the
Design Page limitations, the design
cannot be saved on an original card.
b Memo:
To quit the operation, click Cancel.
b Memo:
“Overwriting” on page 49 and “Saving with a
new name” on page 49.
a Note:
• The original card is inserted correctly
when you hear it snap into place.
• It is not necessary to turn off the
computer when original cards are
inserted or removed from the USB card
writer module.
b Memo:
Patterns that are either too large or have too
many stitches for the embroidery hoop size
selected with the Hoop size selector, are
displayed with a red crossed-out hoop
().
Selected patternsAvailable patterns
