SPECIFICATIONS
ENOM00301-BR
*: with manual
Remark: Specifications subject to change without notice.
Power rated in accordance with NMMA procedures and using ICOMIA standard 28/23.
15
Item
MODEL
R TE TP
Overall Length mm (in) 1055 (41.5)
Overall Width mm (in) 365 (14.4)
Overall Height S·L·UL mm (in) 1085 (42.7) 1325 (48.6) 1362 (53.6)
Transom Height S·L·UL mm (in) 413 (16.3) 562 (22.1) 669 (27.1)
Weight*1
S kg (lb) 52 (115) 55.5 (122) 62.5 (138)
L kg (lb) 53.5 (118) 57.0 (126) 64.0 (141)
UL kg (lb) 55 (121) 58.5 (129) 66.5 (144)
Output kW (Hp) 11.0 (15)
Max. Operating Range rpm 5000-6000
Idle Speed in Forward Gear
rpm 900
Idle Speed in Neutral Gear rpm 950
Engine Type 4-Stroke
Number of Cylinder 2
Bore × Stroke mm (in) 61 × 60 (2.40 × 2.36)
Piston Displacement mL (Cu in) 351 (21.42)
Exhaust System Through hub exhaust
Cooling System Water cooling
Engine Lubrication Trochoid pump
Starting System Manual Electric starter motor*
Ignition System Flywheel Magneto C.D. ignition
Spark Plug NGK DCPR6E
Trim Position 6
Engine Oil mL (fl.oz.) API SF, SG, SH, SJ, SL 10W-30, Approx. 1000 (33.8)
Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5, SAE #80-90, Approx. 370 (12.5)
Fuel
Unleaded regular gasoline : Pump posted
87 Octane (research octane rating of 91)
Fuel Tank Capacity L (US gal) 12 (3.17)
Gear Reduction Ratio 2.15 (13 : 28)
Emission Control System EM (Engine modification)
Operator Sound Pressure
(ICOMIA 39/94) dB (A)
83.9
Hand Vibration Level
(ICOMIA 38/94) m/sec2
2.5
