32
7
ENGINE OPERATION
ENOM00042-0
ENOW00022-A
The engine oil is drained for shipping from
the factory. Be sure to fill the engine to the
proper level before starting engine. (To
properly fill the engine with oil follow the
instructions. See page 58)
ENOW00027-A
Before starting engine for the first time
after reassembling engine or off-season
storage, disconnect stop switch lock and
crank approximately 10 times in order to
prime the oil pump.
ENOM00044-A
ENOW00029-A
When opening fuel tank cap, be sure to fol-
low the procedure described below. Fuel
could blast out through the fuel tank cap in
case the cap is loosened by using another
procedure when internal pressure of fuel
tank is raised by heat from sources such as
sun light.
ENOW00030-B
When using EPA approval fuel tank, only
use a primer bulb/hose assembly that has
a Fuel Demand Valve (FDV) installed in the
fuel hose or a sealing mechanism in the
fuel connector as shown below.
FDV and fuel connector that has an sealing
mechanism prevent pressurized fuel spill-
age when the fuel connector is connected
to the engine.
1. FDV in fuel hose
2. Sealing mechanism in fuel connector
3. Identification
Do NOT use a primer bulb/hose assembly
that does not contain a Fuel Demand Valve
or a sealing mechanism as shown below:
otherwise fuel spillage may occur when the
connector is connected to the engine.
Do not connect fuel connector except
when operating engine. Fuel leakage is a
fire or explosion hazard, which can cause
serious injury or death.
Before starting
CAUTION
CAUTION
1. Fuel feeding
WARNING
WARNING
E15__US_EN_141125N.book 32 ページ ２０１４年１２月２６日 金曜日 午後２時４６分
