REMOVING AND CARRYING THE OUTBOARD MOTOR 53
8
ENOW00071-0
The tilt support device supplied on your
outboard motor is not intended for towing.
It is intended to support the outboard
motor while the boat is docked, beached,
etc.
When transporting a boat on a trailer with
the outboard motor still attached, discon-
nect the fuel line from the outboard motor
beforehand and keep the outboard motor
in the normal running position or on a tran-
som saver bar.
Tiller handle type
To prevent the outboard motor from mov-
ing when it is attached on a boat during
transport on a trailer, properly tighten the
steering friction lever (page 54).
1. Ground clearance should be provided sufficiently.
2. Transom saver bar
ENOW00067-0
Do not go under outboard motor tilted up
even if it is supported by support bar, or
accidental fall of outboard motor could
lead to severe personal injury.
CAUTION
WARNING
