Connecting to RS232/RS485 of CU09
There are two devices which can be used to adapt ”tty01,...tty09, tty10 and tty20” to the
separate Sub–D–9 Connectors (see Figure 3: ):
AspectStation1 RS232 Router, (only for RS232), P/N H5468
AQX RS232/485 Extension Unit, P/N H5714
Both devices have to be connected to the CCU by one or two cables of the following
type:
SCSI Cable P/N 73104
Connecting to RS232/RS485 of CU10
The RS485 Channels (tty10 and tty20) are only avalable at the AQS Backplane, Connec-
tor X3.
Connecting the RS232 Channels ”tty01,...tty09” to the separate Sub–D–9 Connectors the
following parts can be used (see Figure 4: )
AspectStation1 RS232 Router, ( for RS232 only), P/N H5468
AQS RS232 Extension Unit, P/N H9508
RS232 devices have to be connected to the CCU by one or two cables of the following
type:
SCSI Cable P/N 73104
To Next Page
