Flow Unit Installation
26 H155936_3_003
6.4 Temperature Control (optional)
• Connect the inlet and outlet of the temperature control lines to the back of the thermostat.
Figure6.5: Temperature Control Connections
• Set the thermostat to the target temperature; start it and wait for the desired temperature
to be reached.
• Verify that the temperature control liquid returns to the chiller.
• Check for leakages at the upper part of the sample tube holder, all O-rings and seals.
• Check that no liquid appears at the outlet of the transfer lines (for both sample and
temperature control lines).
• Check that the temperature control liquid does not leak into the sample line.
