5.3.2 Mount the Detector to the 2-Theta Axis
The detector fits like other detectors on the universal detector mount.
The detector is equipped with either a 0/90° or a 0° mount (Figure 5.4, Figure 5.6).
1. Move the 2-theta drive to a position where the detector can be placed on the track (approximately
35° 2-theta).
2. Apply the detector against the guidance block (Figure 5.5).
3. Rotate it until its base plate touches the three balls of the support point and fix the detector with the
knurled screw (Figure 5.7).
