BSWA 308/309 BSWA Technology Co., Ltd
101
Example: query custom measure data
02 01 43 44 43 55 31 20 3F 03 3F 0D 0A
Returns: the current custom measure data: Group 0: A-weighting, Fast*, L10, 065.4dB;
Group 1: A-weighting, Fast*, L20, 065.4dB; Group 2: A-weighting, Fast*, L60, 065.3dB;
Group 3: A-weighting, Fast*, L99, 065.1dB; Group 4: A-weighting, Fast, Min, 064.4dB; Group
5: A-weighting, Fast*, Peak, 081.9dB; Group 6: A-weighting, Fast, Sel, 083.8dB; Group7:
A-weighting, Fast, SPL, 065.3dB; Group 8: B-weighting, Fast, SPL, 066.4dB; Group 9:
A-weighting, Fast, SD, 005.6dB; Group10: B-weighting, Fast, SD, 007.2dB; Group 11:
A-weighting, Fast*, E, 2.696E-05dB; Group 12: A-weighting, Fast, Max, 65.5dB; Group 13:
B-weighting, Fast*, Leq, 066.2dB, normal (no overload/under-range). ★Note: Parameters
with * are useless
02 01 41 30 2C 30 2C 30 38 2C 30 36 35 2E 34 2C 30 2C 30 2C 30 39 2C 30
36 35 2E 34 2C 30 2C 30 2C 31 33 2C 30 36 35 2E 33 2C 30 2C 30 2C 31 37
2C 30 36 35 2E 31 2C 30 2C 30 2C 30 35 2C 30 36 34 2E 34 2C 30 2C 30 2C
30 36 2C 30 38 31 2E 39 2C 30 2C 30 2C 30 32 2C 30 38 33 2E 38 2C 30 2C
30 2C 30 30 2C 30 36 35 2E 33 2C 31 2C 30 2C 30 30 2C 30 36 36 2E 34 2C
30 2C 30 2C 30 31 2C 30 30 35 2E 36 2C 31 2C 30 2C 30 31 2C 30 30 37 2E
32 2C 30 2C 30 2C 30 33 2C 32 2E 36 39 36 65 2D 30 35 2C 30 2C 30 2C 30
34 2C 30 36 35 2E 35 2C 31 2C 30 2C 30 37 2C 30 36 36 2E 32 2C 30 03 33
0D 0A
DSLp1_p2_?: Query All the Data of the Sound Level Meter
Instruction
P1
P2
P3
Explanation
DSL
p1: Data
group;
0=SPL;
1=SD;
2=SEL;
3=E;
4=Max;
5=Min;
6=Peak;
7=Leq;
8=LN
p2: Return
manner;
0=Stop return;
1=Single
return;
2=Continuous
return;
3=Integral end
return
Query
parameter: ?
ASCII
D
S
L
0
1
?
Hex
44H
53H
4CH
30H
31H
3FH
Byte
1
1
1
1
1
1
Return
Return the corresponding group data:
