BSWA 308 - Information for Periodic Tests

BSWA 308/309 BSWA Technology Co., Ltd
12
GPS timing function available (option with GPS module)
Language
English, Chinese, Portuguese, Spanish, German, French
Firmware Update
Update firmware via USB port
Conditions
Temperature: -10ºC~50ºC. Humidity: 20%~90%RH
RT Temperature
Real-time temperature display on the main screen
Size (mm)
W70 x H300 x D36
Weight
Approx. 620g, including 4 alkaline batteries
Option
GPS
Receiver Type: 50 Channels; Time-To -First-Fix: Cold Start 27s, Warm
Start 27s, Hot Start 1s; Sensitivity: Tracking -161dBm, Reacquisition
-160dBm, Cold Start -147dBm, Hot Start -156dBm; Horizontal position
accuracy: 2.5m, Timing accuracy: 30ns, Velocity accuracy: 0.1m/s;
Update Rate: 1Hz, Operation Limits: Dynamic≤4g, Altitude<50000m,
Velocity<500m/s
Calibrator
CA111, Class 1, 94dB/114dB, 1kHz
Printer
Mini thermal or dot-matrix printer, RS-232 port
Note 1: Ignore the result outside 20Hz~12.5kHz for type BSWA 309 alone due to microphone
frequency response of Class 2.
Note 2: The data was measured with 40mV/Pa microphone for BSWA 308 and BSWA 309.
Note 3: Measurement according to GB/T 3785 and IEC 61672.
Note 4: Measurement according to GB/T 3241 and IEC 61260.
1.6 Information for Periodic Tests
 Reference sound level: 94.0dB.
 Reference incidence direction: parallel to the incident direction of the microphone.
 Reference point of microphone: the central point of microphone diaphragm.
 Reference incidence direction: direction perpendicular to the microphone diaphragm.
 Reference attenuation of octave spectra: 0dB.
 Reference input signal level of octave spectra: 40mV (94dB for sensitivity of 40mV/Pa).
