BSWA 308/309 BSWA Technology Co., Ltd
94
Example: query USB mode setting
02 01 43 55 4D 44 3F 03 20 0D 0A
Return: the current USB mode is modem mode
02 01 41 32 03 73 0D 0A
GPDp1_p2: Set GPS
Instruction
P1
P2
Explanation
GPD
p1: GPS switch;
0=OFF;
1=ON;
Default: 0
p2: Auto time sync;
0=OFF;
1=ON;
Default: 0
ASCII
G
P
D
0
0
Hex
47H
50H
44H
30H
30H
Byte
1
1
1
1
1
Return
ACK / NAK
Example: set GPS as switch: ON, auto time sync: ON
02 01 43 47 50 44 31 20 31 03 30 0D 0A
Return: ACK
02 01 06 03 06 0D 0A
GPD?: Query GPS Setting
Instruction
Parameters
Explanation
GPD
Query parameter: ?
ASCII
G
P
D
?
Hex
47H
50H
44H
3FH
Byte
1
1
1
1
Return
Return GPS setting
Example: query GPS setting
02 01 43 47 50 44 3F 03 2D 0D 0A
Returns: the current GPS setting is switch=ON, auto time sync=ON
02 01 41 31 2C 31 03 6F 0D 0A
VER?: Query About Information
Instruction
Parameters
Explanation
VER
Query parameter: ?
ASCII
V
E
R
?
Hex
56H
45H
52H
3FH
