4 Logamatic 2107 controls
Introduction to the user interface of the Logamatic 2107 controls.
Fig. 1 Controls on the Logamatic 2107 controls
Item 1: Manual reset high limit (STB)
Item 2: Boiler water thermostat
Item 3: Fuse (10 Amp)
Item 4: Switch for Automatic mode, Emergency mode
Item 5: ON/OFF switch
Item 6: Keys for basic functions
Item 7: Dial
Item 8: Keys for extended functions
Item 9: Display
Item 10: Flap
160
AUT
180
140
120
160
AUT
180
140
120
1
2
3
4
5
7
6
9
8
10
AUTOMATIC
11.15am 71
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications. 11
4
Logamatic 2107 controls

Buderus Logamatic 2107 Specifications

General

Category	Control Systems
Type	Heating Control Unit
Voltage	230 V
Frequency	50 Hz
Protection class	IP20
Ambient temperature	0°C
Application	Heating systems
