7.5 Operating time of the modulating
burner actuator
This feature requires the burner module FM 242 and "MODULATE" burner
setting.
The factory default is "12 seconds".
Changing the operating time of the actuator
USER NOTE
The data can be found in the technical documentation for the installed burner.
+
Press the "Display" key and "Install" key at the same time to call up the service
level. "AMERICAN" appears as the first main menu.
Turn the dial until "BLR TEMP" is shown.
Press "Display" to call up a submenu.
"FREEZE TEMP" appears.
Turn the dial until "MOD TIME" is shown.
+
Hold down the "Display" key and turn the dial until the required value appears
(in this case "15").
Release "Display" to store your input.
Press "ENTER" to return to the next higher level.
12
MOD TIME
15
MOD TIME
Input range Factory setting
Operating time of the actuator 5 – 60 seconds 12 seconds
