Setting parameters and display data for the Logamatic 2107
2
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications. 7
2 Setting parameters and display data for the Logamatic 2107
Press the "Display" key and "Install" key at the same time to call up the service
level (see Chapter "Keys for extended functions", page 14).
Display
AMERICAN Language selection
BOILER Boiler parameters
FROST AO Freeze protection limit
BUILDING Building response
2-STAGE
1
Burner type
1
MIN MOD
2
Minimum modulation output
2
TIME RUN
2
Minimum burner run time
2
PUMPLOGIC Pump logic threshold
MAX TEMP Maximum boiler switch-off temperature
CIRCUIT 01 Heating circuit 1 installation parameters (unmixed heating circuit)
PERIM HTG Heating system
REF TEMP Design temperature
REMOTE 1 Remote control ON/OFF
DIFF T
3
Room temperature hook-up
3
OA SETBACK Type of setback
OFFSET Room temperature offset
CIRCUIT 02
5
Heating circuit 2 installation parameters (mixed heating circuit)
4
UND-FLOOR Heating system
REF TEMP Design temperature
DHW PR
5
DHW priority
5
MAX TEMP Maximum heating circuit temperature
REMOTE 2 Remote control ON/OFF
DIFF T
3
Room temperature hook-up
3
OA SETBACK Type of setback
OFFSET Room temperature offset
