19 Operating values at the service level/setup report
Input range Factory setting Setting
Language American American
Building response -4 – 50°F (-20°C – 10°C) 41°F (5°C)
Type of construction 1, 2, 3 2
Burner system 1-stage/2-stage/modulating 1-stage
Modulating output 10 %–60 % 30 %
Operating time of the burner
actuator
5s–60s 12 s
Pump logic 59 – 140°F (15°C – 60°C) 104°F (40°C)
Maximum temperature 158 – 210°F (70°C – 99°C) 176°F (80°C)
Heating circuit 01 None/PERIM HTG PERIM HTG
Heating circuit 02 None/PERIM HTG/FLOOR HTG FLOOR HTG
Reference temperature (PERIM HTG
1 or 2)
86 – 194°F (30 °C – 90°C) 167°F (75°C)
Reference temperature (FLOOR
HTG 2 only)
86 – 140°F (30°C – 60°C) 113°F (45°C)
Remote control for heating circuit 1 OFF/ON OFF
Remote control for heating circuit 2 OFF/ON OFF
Offset circuit 1 OFF/2 – 18°F (1 – 10°C) 6°F (3°C)
Offset circuit 2 OFF/2 – 18°F (1 – 10°C) 6°F (3°C)
Setback type for heating circuit 1
Outdoor setback
Room setback
Setback
Switch-off
Outdoor setback
Setback type for heating circuit 2
Outdoor setback
Room setback
Setback
Switch-off
Outdoor setback
Further information on this can be found on the next page.
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications.58
