9.2 Maximum storage tank temperature in
solar mode
The solar heating system will collect all solar heat that can be harvested. It will
only stop when there is not sufficient insolation or to protect the tank from
overheating. When "MAX SOL T" is reached at the top tank sensor FB, the solar
pump is switched off.
WARNING!
RISK OF SCALDING
The DHW temperature can be set to a maximum of 194°F (90°C). At DHW
temperatures over 122°F (50°C) there is a risk of scalding at the taps if no
thermostatic mixing valve (anti-scald device) has been installed.
z If the DHW temperature is set above 122°F (50°C), you should only draw
off mixed hot and cold water.
+
Press the "Display" key and "Install" key at the same time to call up the service
level. "AMERICAN" appears as the first main menu.
Turn the dial until the "SOLAR" main menu appears.
Press "Display" to call up a submenu.
"SOLAR ON" appears.
Turn the dial until "MAX-SL SR" appears.
+
Hold down the "Display" key and turn the dial until the required value appears
(in this case "194°F").
Release "Display" to store your input.
Press "ENTER" to return to the next higher level.
Input range Factory setting
Max sol T
140 – 194°F (60°C – 90°C) 167°F (75°C)
USER NOTE
Take the lime content of the local drinking water into consideration when
determining the "MAX-SL SR" setting in order to prevent the tank scaling up.
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications.44
