Press the "Display" key and "Install" key at the same time to call up the service
level. "AMERICAN" appears as the first main menu.
Turn the dial until "CIRCUIT 01" or "CIRCUIT 02" is displayed.
"CIRCUIT 02" setting (heating circuit with mixing valve)
Press "Display" to call up a submenu.
"RADIATOR" appears.
CIRCUIT 02
FLOOR HTG
Input range Factory setting
Heating circuit 1
NO SYSTEM
PERIM HTG
PERIM HTG
Heating circuit 2
NO SYSTEM
FLOOR HTG
FLOOR HTG
Logamatic 2107 controls - We reserve the right to make any changes due to technical modifications. 31
8
Heating circuit data

Buderus Logamatic 2107 Specifications

General

Category	Control Systems
Type	Heating Control Unit
Voltage	230 V
Frequency	50 Hz
Protection class	IP20
Ambient temperature	0°C
Application	Heating systems
