Installation and maintenance instructions Logano G334 X gas-fired boiler • Issue 09/2005
We reserve the right to make any changes due to technical modifications.
Parts lists14
14 Parts lists
The following spare parts are available for Buderus
heating systems. If there are more than one Buderus
article numbers at one item number, these numbers are
listed in the columns corresponding to the various
models. In other cases the number of components is
shown.
Jacket assembly (Î Fig. 43)
Item
no.
Description Buderus
article number
Model 73
Quantity/m
odel
Model 92
Quantity/m
odel
Model 116
Quantity/m
odel
Model 132
Quantity/m
odel
10 Jacket complete 05024- 250 252 254 256
20 Left side jacket panel 63002797 1 1 1 1
30 Clip nut SNU-5743 05834364 2 2 2 2
40 Right side jacket panel 63003095 1 1 1 1
50 Front jacket panel 05024- 037 039 041 043
60 "Buderus" plate 67902841 1 1 1 1
70 Top front jacket panel 05024- 067 069 071 073
80 Top back jacket panel 05024- 087 089 091 093
90 Cover panel 63016429 1 1 1 1
Mounting kit no. 1 05015951 1 1 1 1
Tab. 9 Jacket assembly
