50
Installation and maintenance instructions Logano G334 X gas-fired boiler • Issue 09/2005
We reserve the right to make any changes due to technical modifications.
Parts lists14
Tab. 10 Block assembly
Block assembly - component parts (Î Fig. 44)
Item
no.
Description Buderus
article number
Model 73
Quantity/
model
Model 92
Quantity/
model
Model 116
Quantity/
model
Model 132
Quantity/
model
10 Block assembly 67900- 361 362 363 365
20 Mounting Plate 05015257 2 2 2 2
30 Non-combustible base 05024- 146 148 150 152
40 Bolt M8x25 see M-kit no. 2 4 4 4 4
50 Spring ring see M-kit no. 2 4 4 4 4
60 Nut M8-8-A3K see M-kit no. 2 4 4 4 4
70 Block clamp see M-kit no. 2 4 4 4 4
80 Return pipe 05584754 1 1 1 1
90 Supply pipe 05584752 1 1 1 1
100 3/4" Elbow 99908401 1 1 1 1
110 Safety relief valve 05947650 1 1 1 1
120 Black jacket panel 63002- 789 793 794 795
130 Clip nut SNU-5743 see M-kit no. 2 2 2 2 2
140 Back screening panel 05512- 532 534 536 538
150 Screw C-ST4.8x22 see M-kit no. 2 2 2 2 2
160 Insulation plate 05015273 2 2 2 2
170 Immersion well R3/4“x100 compl. 05446065 1 1 1 1
180 Cable way 05495471 1 1 1 1
190 Screw 3.5x9.5-A3T see M-kit no. 2 1 1 1 1
200 Insulation 67900567 1 1 1 1
210 Middle panel 63002- 768 769 770 771
220 Tridicator set 05900076 1 1 1 1
230 Flue collector 05321- 772 774 776 779
240 Flueway access panel 05371- 926 928 930 932
250 Gasket cord GP6x1825 63020958 1 - - -
250 Gasket cord GP6x2185 63020958 - 1 - -
250 Gasket cord GP6x2545 63020958 - - 1 -
250 Gasket cord GP6x2905 63020958 - - - 1
250 Gasket cord GP6x10000 05822706 - - - -
Sealling material Buderus-3055 63014361 1 1 1 1
260 Bolt M6x16-MS see M-kit no. 3 2 2 2 2
270 Washer A6.4 see M-kit no. 3 2 2 2 2
