Buhnen HB 710 - Melt Tank

Spare parts
18
10.1.2 Melt Tank
4, H206648
Spare parts list
Pos. Order no. Quantity Designation
1 H206004 1 Temperaturetracer
2 H206018 1 Hose
3 H206020 1 Rib
4 H206648 1 Heater
5 H217195 1 Tankunit
6 H217196 1 frontkitunitbead
7 KDN0517 2 Screw
8 KDN0529 1 Toothedwasher
9 KDN0681 2 Screw
10 KDN0704 1 Screw
11 KDN0726 1 Washer
12 LD0074 3 O-ring
13 LDF0019 2 Sealingring
14 LDH0143 2 O-ring
15 LDN0131 1 O-ring
16 MC0094 1 Hoseconnector
17 NC0093 1 Thermostat
