Buhnen HB 710 - Page 3

1
Working bracket
Working brackeet
Applicator
Pos. Description Pos. Description
1 Compressedairconnection 10 Lever
2 Waterseparator 11 Closurecap
3 Pressureregulator 12 Suspensionpoint
4 Pressuregauge 13 Protectioncap
5 Digitaldisplay 14 Sprayairchoke
6 Start/Stopbutton 15 Protectioncap
7 Setbutton 16 Trigger
8 Downbutton  17 Handle
9 Upbutton 18 Standhoop
Arrangement
