LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 52
4.4 HORIZONTAL BEATER (x 2) WITH SPINNING DISCS (HBD) – CONTINUED
KEY QTY PART No. DESCRIPTION KEY QTY PART No. DESCRIPTION
1 BC290 DUPLEX SPROCKET 23T 3020 43 4
73155/1 +
73375
BOLT & NUT M16x50 G12.9
(INNER)
1 BC281/1
DUPLEX SPROCKET 16T 2517
(OPT)
44 4 73155 + 73375
BOLT & NUT M16x50 G8.8
(OUTER)
25 1 B1178/1 BEARING UCFX10-50mm 45 4 B1130/18 PADDLE INC NUTS & BOLTS
26 1 BC222
DUPLEX TENSION SPROCKET
C/W BEARING RHS
46 1 B4176/1 SPINNER DECK RUBBER WB
27 1 B8920 OIL TANK FOR OILER 47 1 B4186/1 RUBBER CLAMP STRIP
1 DMS1328-17 DRIVE SHAFT SRT18 (STD) 48 12
73035 + 73359
+ 74682
BOLT, NUT & WASHER
M8x40
1 DMS1328-15
DRIVE SHAFT SRT20 (OPT) 49 1 B8450 TOP DOOR
29 1 42506
TORQUE LIMITER UNION
ASSY 1-3/4" 6 SPLINE
50 1 B8451 BOTTOM DOOR
1 B3183 HBD GEARBOX SRT18 (STD) 51 1 B4125 CANOPY RUBBER
1 B3188 HBD GEARBOX SRT20 (OPT) 52 1 B4186/1 RUBBER CLAMP STRIP
31
1 B5364 PTO GEARBOX GUARD 53 12
73035 + 73359
+ 74682
BOLT, NUT & WASHER
M8x40
32 2 B5326 WEAR END PLATE 54 1 AMS1867-4 CANOPY DOOR HINGE ASSY
33 2
73830 + 73367
+ 74684
CSK BOLT, NUT & WASHER
M12x50
55 1 AMS1867-3 CANOPY DOOR HINGE ASSY
34 2 B5325 HARDOX WEAR PAD WRAP 56 2 65093 RAM CANOPY DOOR
35 10
B5330 + 73367
+ 74684
CSK BOLT, NUT & WASHER
M12x40
57 2 DMS2381 PIVOT PIN
36 2 B8338
MOUNTING FLANGE ASSY
SRT18 (STD)
58 2 DMS0940-1 TOP RAM PIN
2 B8338/1
MOUNTING FLANGE ASSY
SRT20 (OPTION)
59 2 DMS0940-2 BOTTOM RAM PIN
37 2
73128/1 +
74703
BOLT & SPRING WASHER
M14x45 GR 10.9
60a 1 AMS4253-3 LIGHT BRACKET LHS 500**
38 16 73095 BOLT & NUT M12x50 60b 1 AMS4252-3 LIGHT BRACKET RHS 500**
39 1 B8370H LHS SPINNING DISC ASSY 61 2 70009/3 LED REAR LAMP
40 1 B8342H RHS SPINNING DISC ASSY 62 2 70081 TRIANGLE REFLECTOR - RED
41 2 B8356/18 BLADE HOLDER LHS
* 1 GEARBOX SEE FLOOR DRIVE ASSY
42 2 B8357/18 BLADE HOLDER RHS
24
28
30
** 600mm wide brackets available by request
