Burkert 2000 - Page 19

Type 2000
Technical data
19
SFA, ø40 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN15 DN20
Fig.12: Actuator ø40 mm, control function A, flow direction above the seat
SFA, ø50 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN15 DN20 DN25
Fig.13: Actuator ø50 mm, control function A, flow direction above the seat
SFA, ø63 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN20 DN25 DN32 DN40 DN50
Fig.14: Actuator ø63 mm, control function A, flow direction above the seat
