Burkert 2000 User Manual

Type 2000
Technical data
20
SFA, ø80 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN25 DN32 DN40 DN50 DN65
Fig.15: Actuator ø80 mm, control function A, flow direction above the seat
SFA, ø100 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN32 DN40 DN50 DN65
Fig.16: Actuator ø100 mm, control function A, flow direction above the seat
SFA, ø125 mm
Medium pressure
[bar]
Pilot pressure
[bar]
DN40 DN50 DN65
Fig.17: Actuator ø125 mm, control function A, flow direction above the seat
6.5 Mechanical data
Actuator size See type label
Installation position any, preferably actuator face up
Materials
Threaded connection Red bronze
Stainless steel 316L

Burkert 2000 Specifications

General

Model	2000
Manufacturer	Burkert
Ambient Temperature	-10 to +60 °C
Protection Class	IP65
Operating Temperature	-10 to + °C
Seal Material	FKM
Operating Pressure	0- bar
Fluid Temperature	-10 to + °C
