Burkert 2000 User Manual

Type 2000
Technical data
21
Welded connection and clamp connec-
tion
Stainless steel 316L
actuator PA or PPS
Seal PTFE
(NBR, FKM, EPDM on request)
Packing gland (with silicone grease)
Stainless steel valve body
PTFE V-rings with spring compensation
Packing gland (with silicone grease) Red
bronze valve body
PTFE and FKM V-rings with spring compensation
Ports
Threaded connection G⅜...G2½ (VA G3)
(NPT on request)
welded connection in accordance with EN 1127,
DIN 11850 R2
Clamp connection in accordance with ISO 2852, ASME BPE,
BS 4825
Pilot air port Push-in connector 6/4 mm or threaded connection ¼"
More on request

Burkert 2000 Specifications

General

Model	2000
Manufacturer	Burkert
Ambient Temperature	-10 to +60 °C
Protection Class	IP65
Operating Temperature	-10 to + °C
Seal Material	FKM
Operating Pressure	0- bar
Fluid Temperature	-10 to + °C
