Type 2000
Replacement parts, accessories
33
12 REPLACEMENT PARTS, ACCESSORIES
CAUTION!
Risk of injury and/or damage due to the use of incorrect parts.
Incorrect accessories and unsuitable spare parts may cause injuries and damage the device and its envir-
onment.
▶ Use original accessories and original spare parts from Bürkert only.
12.1 Installation tools
Installation wrench for packing gland (series-production status up to January 2013)
Spindle [mm] Seat size Order No.
ø10 15...40 665700
ø14 32...65 665701
Tab.8: Installation wrench
Modified socket wrench for packing gland (series-production status as of January 2013)
Spindle [mm] Seat size Width across flats Order No.
ø10 15...50
6
19 683221
ø14 32...80 21 683223
Tab.9: Modified socket wrench
Special wrench for turning the actuator (series-production status up to end of 2011)
Order No. 665702
Tab.10: Special wrench
If you have any questions, contact your Bürkert sales department.
12.2 Replacement part set
The following spare part sets are available for the device:
▪ Valve set consists of swivel plate with PTFE seal, pin and seal.
▪ Seal set for actuator consists of the seal and wearing parts of the actuator.
6
As of series-production status January 2017 also for seat size 50
