Burkert 2300 - INSTALLATION; Safety instructions

22
Installation
 Spindle     1.4401/1.4404
 Spindleguide   1.4401/1.4404/316L
Connections
Pilotairport    preparedfordirectconnection
Mediumconnection  Threadedport:G½–G2½
(NPT,RConrequest)
Weldedconnection:asperENISO1127
(ISO4200),DIN11850R2
Otherconnectionsonrequest
Media
Controlmedium   neutralgases,air
Flowmedia    Water,Alcohol,Fuel,
Hydraulicliquids,Salinesolutions,
Lyes,Organicsolvents
Installation position  asrequired,preferablywithactuatorin
uprightposition
Protection class   IP67inaccordancewithIEC529/EN60529
8 INSTALLATION
8.1 Safety instructions
DANGER!
Danger – high pressure in the equipment!
▶ Beforelooseningthelinesandvalves,turnothepressure
andventthelines.
WARNING!
Risk of injury from improper installation!
▶ Installationmaybecarriedoutbyauthorisedtechnicians
onlyandwiththeappropriatetools!
Risk of injury from unintentional activation of the system and
an uncontrolled restart!
▶ Securesystemfromunintentionalactivation.
▶ Followingassembly,ensureacontrolledrestart.
For control function I – Danger if pilot pressure fails!
ForcontrolfunctionIcontrolandresettingoccurpneumati-
cally.
Ifthepressurefails,nodenedpositionisreached.
▶ Toensureacontrolledrestart,rstpressurizethedevicewith
pilotpressure,thenswitchonthemedium.
Risk of injury from moving parts in the device!
▶ Donotreachintoopenings.
english
Type 2300
