Replacement parts
12 REPLACEMENT PARTS
WARNING!
Risk of injury when opening the actuator!
Theactuatorcontainsatensionedspring.Iftheactuatoris
opened,thereisariskofinjuryfromthespringjumpingout!
▶ Theactuatormustnotbeopened.
CAUTION!
Risk of injury and/or damage by the use of incorrect parts!
Incorrectaccessoriesandunsuitablereplacementpartsmay
causeinjuriesanddamagethedeviceandthesurrounding
area.
▶ Useonlyoriginalaccessoriesandoriginalreplacementparts
fromBürkert.
12.1 Replacement part sets
Replacementpartsetsfortheangle-seatcontrolvalveType2300:
• Controlconeset
consistingofcontrolcone,dowelpin,sealandlubricant.
• Sealingsetforpackinggland
consistingoftheindividualpartsofthepackinggland,sealand
lubricant(the(modied)socketwrenchisnotincludedinthe
sealingset).
• Spindleguideforpackinggland
consistingofVAspindleguide,sealandlubricant.
Control cone set
DN Actuator size
[mm]
Order no.
PTFE / Steel Steel / Steel
15 ∅
50,∅ 70 170 315 170 322
20 ∅
50,∅ 70 170 316 170 323
25 ∅
50,∅70,∅ 90 170 318 170 324
32 ∅ 70 170 319 170 325
∅
90,∅ 130 226 941 226 925
40 ∅
90,∅ 130 226 945 225 423
50 ∅
90,∅ 130 226 948 225 426
65 ∅ 130 226 950 225 427
Tab. 23: Control cone set
Sealing set for packing gland
Spindle ∅
[mm]
DN
Actuator size
[mm]
Order no.
10
15–32
∅ 50
216 436
∅ 70
14
25–50
∅ 90
216 438
∅ 130
22 65 ∅ 130 252 545
Tab. 24: Sealing set for packing gland
