Burkert 2300 - Page 42

42
Replacement parts
VA spindle guide for packing gland
Spindle ∅ DN Actuator size Order no.
10
15 ∅
50,∅ 70 246 577
20/25 ∅50,∅ 70 246 578
32 ∅ 70 246 582
14
25 ∅ 90 246 579
32 ∅
90,∅ 130 246 583
40 ∅
90,∅ 130 246 593
50 ∅
90,∅ 130 246 594
22 65 ∅ 130 252 544
Tab. 25: VA spindle guide for packing gland
4
6
1
2
3
1Seal
2Controlcone
3Dowelpin
4Sealingsetfor
packinggland
SP10/SP14
5Sealingsetfor
packingglandSP22
6VAspindleguide
SP10/SP14
7VAspindleguide
SP22
5
7
Controlconeset
Fig. 37: Replacement parts
english
Type 2300
