Burkert 2301 - Assembly Tools

46
Spare parts
Seal set for packing gland
Body DN
Actuator
size
Order
number
Standard
device
Order
number
Hot water
device
Order
number
High tem-
perature
device
10/15–25
∅50
216436 372658 372659
∅70
20–50
∅90
216438 372656 372657
∅130
65–100 ∅130 216545 - 372651
Tab.22: Sealsetforpackinggland
VA spindle guide for packing gland
Spindle∅ DN Actuator size Order number
10
10/15 ∅
50,∅70 00246577
20–25 ∅
50,∅70 00246578
32 ∅70 00246582
14
20 ∅90 60004091
25 ∅90 00246579
32 ∅
90,∅130 00246583
40 ∅
90,∅130 00246593
50 ∅
90,∅130 00246593
22 65–100 ∅130 00252543
Tab.23: VAspindleguideforpackinggland
12.2 Assembly tools
OnlyforPEEKspindleguide:
Installation wrench for packing gland
(Series-productionstatusuptoJanuary2013)
Installation wrench Order number
Spindlediameter10mm 665700
Spindlediameter14mm 665701
Tab.24: InstallationwrenchforPEEKspindleguide
Modied socket wrench for packing gland
(Series-productionstatusasofJanuary2013)
SW
Socket wrench DN SW Order
number
Spindle
∅10mm
15 19 683220
Spindle
∅10mm
20–25 21 683222
Spindle
∅14mm
25–50 21 683223
Tab.25: Modiedsocketwrench
