Structure and function
5.4.2 Device variants
Actuator sizes
Theglobecontrolvalveisavailableforthefollowingactuator
sizes,dependingontheDN:
Housing size DN Available actuator size ø[mm]
15 50 70 -
-
20 50 70 90
25 50 70 90
32
-
90 130
40 90 130
50 90 130
65
-
130
80 130
100 130
Tab. 1: Actuator sizes
5.5 Intended area of application
Observethemaximumpressureandtemperaturerange
onthetypelabel!
• Neutralgasesandliquidsupto25bar.
• Vapourupto230°CforsteelandPEEKvalveseatseal(see
chapter“7.4.2”).
Vapourupto130°CforPTFEvalveseatseal.
Hotwaterupto200°CforsteelandPEEKvalveseatseal(see
chapter“7.4.2”).
•
Aggressivemedia
6 STRUCTURE AND FUNCTION
TheType2301globecontrolvalvecanonlybeusedin
combinationwithacontrolunit.
Possible control units are:
PositionerType8692,8694and8696
ProcesscontrollerType8693
6.1 Structure
Theglobecontrolvalveconsistsofapneumaticallyoperated
pistonactuator,acontrolconeanda2/2-wayglobebody.
Thecontrolconeismodularlyconnectedtotheactuatorspindle
viaaspring-typestraightpin,andcanthusbequicklyreplaced.
Nearly all line connections are possible for the body. Bushing,
weldedconnectionandangeareoeredasthestandarddevice.
Thevalveseatsarescrewedin.Reducedseatsizesareeasyto
achievebyreplacingthescrewed-invalveseats.Theowdirection
isalwaysbelowthevalveseat.
Thedescriptionofthecontrolfunctions(CF)canbe
foundinchapter“6.2.1Controlfunctions(CF)”.
