Chlorine sensor
568524
1)
and 568523
2)
Instructions "Trace" chlorine sensor
565164
→ Hold the shaft upright and slowly insert it into the filled membrane cap.
→ Hold the membrane cap and slowly screw the shaft clockwise onto the
membrane cap. If a resistance occurs because of the seal, continue
screwing until the working electrode and the bottom of the membrane
cap are in contact: the membrane then has a convex curvature.
→ Make sure the shaft is tightly fastened to the membrane cap:
- do not put your fingers on the vent because excess electrolyte must
flow out through the vent;
- the membrane has a convex curvature: do not touch nor adjoin the
membrane. Do not thump the membrane else it would be damaged
and unusable.
→ Remove excess electrolyte with a cloth dampened with water.
→ Cover the vent with the hose ring.
1) or other chlorine sensor for operation at constant pH
2) or other chlorine sensor having a reduced pH-dependency
17
Installation and wiring
Type 8232
english
