Operating Instructions No. 803 925 37
english
Electrical connection:
4-pole M12 round plug:
Pin 1: Bus +
Pin 3: Bus -
PG screw fitting with connection terminals:
Opening the housing.
If necessary, insert the supplied seal for the AS interface flat cable into the
PG screw fitting.
Connect the wires to the terminals according to the connection plan.
