71 of 166

6.3.2.6.2 Measurement curve reference

The DIGIFORCE

9311 provides the following X-references for the measurement curve:

Reference Absolute

The DIGIFORCE

9311 references the

measurement curve to the absolute zero

point of the measurement system on the X-

channel (e.g. displacement sensor).

Final force

The last measurement point of the forward

measurement curve is the reference point

(X = 0). For a forward and return curve, the

return point is the reference.

Y reference line overrun,

Y reference line underrun

The reference point is where the curve

crosses above or below the set Y-level

(Y reference line).

<value input> Enter the value for the Y-level.

Y trigger overrun,

Y trigger underrun

The reference point is where the curve

crosses above or below the set Y-level

(Y trigger).

Note: For the "Crossing trigger threshold"

reference, the DIGIFORCE

9311

does not start saving curve data

until the trigger event has occurred.

The measurement, however, must

be started before the trigger event.

<value input> Enter the value.
