99 of 166
Parameters in "Realtime switchpoints S1 … S6"
Value Limit threshold Enter the limit threshold
Unit Unit display Displays the units for the measurement
channel
Channel X, Y
Select the active measurement channel for the
respective switching signals S1 to S6
Active High / Low Select whether signal is active high or active
low
Reference Absolute / Y-trigger Reference for measurement channel X
Absolute:
The limit threshold is referred to the absolute
value of measurement channel X.
Y-trigger:
The limit threshold is referred to the trigger
event (for further details, please see section
6.3.2.6 "Measurement mode” on page 69).
Note: You can only select the Y trigger
reference if crossing the Y trigger
threshold is set as the "Reference"
parameter in the "Measurement
Note: Outputs S1 and S2 are permanently assigned to specific PLC outputs. The assignment for
outputs S3 to S6 can be custom-set (see section 6.3.4.1 “PLC outputs” on page 105).
