BUTZBACH STAE - Door leaf design (view from inside)

Design and function
Butzbach GmbH Industrietore Original operating manual sliding doors_V1 13/01/2021 17
5.3 Door leaf design (view from inside)
Figure 3 Mechanical design of the door leaf
Legend
01 Wheel
10 Safety edge control
02 Pass door*
11 Push buttons
03 Row of windows*
12 Warning signal device
04 Truck door control system*
13 Buffer
05 Truck door*
14 Frame part
06 Sliding door drive unit
15 Door filling
07 Emergency operation
16 Current collector
08 Sliding door control system
17 Guide roller
09 Tow eye
18 Truck door drive unit*
*optional
