9.2.4 Inspection and maintenance plan for sliding doors
The table shown below provides information about the annual testing criteria of the consumable parts in
accordance with DIN EN 13241 2016-12.
Consumable part
STA
STAE
STTE
STRE
Type of test
Maintenance / repair
Sealing components
Soil liner
X
X
X
X
Inspect for wear /
damage
Replace if there is
noticeable damage /
wear
Vertical rubber profiles
X
X
X
X
Vertical rubber semi-circular
pieces
X
X
X
X
Wool felt strips with
aluminium profile
X
X
X
X
Seal leading edges
X
X
X
X
Brush seal
X
X
X
X
Rubber and aluminium
profiles for middle seal
X
X
X
X
Mechanical components (1)
Motor
X
X
X
Inspect for wear /
damage according to
the manufacturer's
specifications
Replace if there is
noticeable damage /
wear
Drive wheel, bearing, flange,
knurl
X
X
X
X
Inspect for wear /
damage / noises
Replace if there is
noticeable damage /
wear
Mechanical components (2)
General bearing assembly
for the wheels (LR)
X
X
X
X
Inspect for wear /
damage
Replace if there
is noticeable
damage / wear
Chain, pinion, drive shaft,
chain tensioner
X
X
X
Wheel, bearing, flange
X
X
X
X
Latch elements for manual
latching
X
Pendulum brake, brake
pad, pendulum, locking
disc, flange
X
Guide axle, axial bearing -
block
X
X
X
X
Steel guide rollers
X
X
X
X
Lower metal covers, quick-
release fasteners
X
X
X
X
Cable pulley; cable, bearing
assembly, cable clamps
X
Connectors: bolts, hinges
X
X
X
X
POM and Vulkollan rollers for
the guide rollers
X
X
X
X
Inspect for wear /
damage
Replace if there is
noticeable damage /
wear (after eight years
at the latest)
Electrical components
Lamp, indicator light
X
X
X
Check for proper
functioning
Replace if there is
noticeable damage /
wear or does not function
properly
Escape lighting
X
X
X
Control elements; buttons
X
X
X
Limit switch, in general
X
X
X
Contactless limit switch
including magnets
X
X
X
Safety sensors
X
X
X
Safety edge control (SKS)
X
X
X
Control system
X
X
X
